IGBT with Anti-Parallel Diode

产品详细介绍

art Number	Status	Package	Configuration	VCE(max)	IC (max)		VCE(sat)(typ)	EON	EOFF	Qg	VF	Qrr	Irm
				VCE(max)	25°C	100°C	VCE(sat)(typ)	EON	EOFF	Qg	VF	Qrr	Irm
				V	A	A	V	mJ	mJ	nC	V	µC	A
AOB10B60D	New	TO263	IGBT with Anti-Parallel Diode	600	20	10	1.53	0.26	0.07	17.4	1.52	0.25	5
AOB10B65M1	New	TO263	IGBT with Anti-Parallel Diode	650	20	10	1.6	0.18	0.13	24	1.9	0.4	3.8
AOB15B60D	New	TO263	IGBT with Anti-Parallel Diode	600	30	15	1.6	0.42	0.11	25.4	1.43	0.48	5.8
AOB15B65M1	New	TO263	IGBT with Anti-Parallel Diode	650	30	15	1.7	0.29	0.2	32	1.77	0.7	4.7
AOB5B60D	New	TO263	IGBT with Anti-Parallel Diode	600	10	5	1.55	0.14	0.04	9.4	1.46	0.23	4.4
AOB5B65M1	New	TO263	IGBT with Anti-Parallel Diode	650	10	5	1.57	0.08	0.07	14	1.8	0.24	2.78
AOD5B60D	New	TO252	IGBT with Anti-Parallel Diode	600	10	5	1.55	0.14	0.04	9.4	1.46	0.23	4.4
AOD5B65M1	New	TO252	IGBT with Anti-Parallel Diode	650	10	5	1.57	0.08	0.07	14	1.8	0.24	2.78
AOK10B60D	New	TO247	IGBT with Anti-Parallel Diode	600	20	10	1.53	0.32	0.12	17.4	1.52	0.25	5
AOK15B60D	New	TO247	IGBT with Anti-Parallel Diode	600	30	15	1.6	0.51	0.11	25.4	1.43	0.48	5.8
AOK20B120D1	New	TO247	IGBT with Anti-Parallel Diode	1,200	40	20	1.54	-	0.94	67.5	1.33	-	-
AOK20B120E1	New	TO247	IGBT with Anti-Parallel Diode	1,200	40	20	1.68	-	0.83	60.5	1.6	-	-
AOK20B120E2	New	TO247	IGBT with Anti-Parallel Diode	1,200	40	20	1.75	-	0.82	53.5	1.6	-	-
AOK20B135D1	New	TO247	IGBT with Anti-Parallel Diode	1,350	40	20	1.57	-	1.05	66	1.46	-	-
AOK20B135E1	New	TO247	IGBT with Anti-Parallel Diode	1,350	40	20	1.8	-	0.8	58	1.6	-	-
