100V N-CH

产品详细介绍

Product Family	Product Name	Marking	Package	Vds [min V]	Id [A] 25℃	Vgs(th) [max V]	Rds(on) [max mohm] at Vgs=		Qg [nC] at 10V	Qgs [nC]	Qgd [nC]	Configuration	Downloads
Product Family	Product Name	Marking	Package	Vds [min V]	Id [A] 25℃	Vgs(th) [max V]	10V	4.5V	Qg [nC] at 10V	Qgs [nC]	Qgd [nC]	Configuration	Downloads
100V N-Ch	HGP025N10S	GP025N10S	TO-220	100	180	4.0	2.5	-	192	45	34	Single
100V N-Ch	HGB022N10S	GB022N10S	TO-263	100	180	4.0	2.2	-	192	45	34	Single
100V N-Ch	HGB027N10S	GB027N10S	TO-263	100	120	4.0	2.7	-	125	36	14	Single
100V N-Ch	HGK029N10S	GK029N10S	TO-220	100	120	4.0	2.9	-	125	36	14	Single
100V N-Ch	HGP030N10S	GP030N10S	TO-220	100	120	4.0	3.0	-	125	36	14	Single
100V N-Ch	HGP037N10S	GP037N10S	TO-220	100	120	4.0	3.7	-	118	27	21	Single	Datasheet
100V N-Ch	HGB037N10S	GB037N10S	TO-263	100	120	4.0	3.4	-	118	27	21	Single	Datasheet
100V N-Ch	HGK037N10M	GK037N10M	TO-247	100	120	4.0	3.7	-	124	28	42	Single
100V N-Ch	HGP037N10M	GP037N10M	TO-220	100	120	4.0	3.7	-	124	28	42	Single
100V N-Ch	HGB037N10M	GB037N10M	TO-263	100	120	4.0	3.4	-	124	28	42	Single
100V N-Ch	HGP045N10S	GP045N10S	TO-220	100	100	4.0	4.5	-	112	26	20	Single	Datasheet
100V N-Ch	HGB045N10S	GB045N10S	TO-263	100	100	4.0	4.2	-	112	26	20	Single	Datasheet
100V N-Ch	HGP045N10M	GP045N10M	TO-220	100	100	4.0	4.5	-	118	27	40	Single
100V N-Ch	HGB045N10M	GB045N10M	TO-263	100	100	4.0	4.2	-	112	26	40	Single
100V N-Ch	HGP052N10S	GP052N10S	TO-220	100	100	4.0	5.2	-	92	20	15	Single
100V N-Ch	HGB052N10S	GB052N10S	TO-263	100	100	4.0	4.9	-	92	20	15	Single
100V N-Ch	HGN052N10SL	GN052N10SL	DFN5x6	100	80	2.4	5.0	6.5	95	22	16	Single
100V N-Ch	HGP082N10M	GP082N10M	TO-220	100	60	4.0	8.2	-	56	14	18	Single	Datasheet
100V N-Ch	HGB082N10M	GB082N10M	TO-263	100	60	4.0	8.2	-	56	14	18	Single
100V N-Ch	HGP077N10SL	GP077N10SL	TO220	100	60	2.4	7.7	9.7	49	12	7	Single
100V N-Ch	HGN077N10SL	GN077N10SL	DFN5x6	100	60	2.4	7.7	9.7	49	12	7	Single
100V N-Ch	HGD077N10SL	GD077N10SL	DPAK	100	60	2.4	7.7	9.7	49	12	7	Single
100V N-Ch	HGS085N10SL	GS085N10SL	SO-8	100	14	2.4	8.5	10.5	49	12	7	Single	Datasheet
100V N-Ch	HGS120N10SL	GS120N10SL	SO-8	100	11.5	2.4	12.0	15.0	36	8	4	Single
100V N-Ch	HGN120N10SL	GN120N10SL	DFN5x6	100	50	2.4	12.0	15.0	36	8	4	Single
100V N-Ch	HGI120N10SL	GI120N10SL	IPAK	100	50	2.4	12.0	15.0	36	8	4	Single
100V N-Ch	HGP200N10SL	GP200N10SL	TO220	100	47	2.4	20.0	26.0	19	4	3	Single
100V N-Ch	HGP260N10SL	GP260N10SL	TO220	100	40	2.4	26.0	30.0	17	3	2	Single
100V N-Ch	HGB200N10SL	GB200N10SL	TO-263	100	47	2.4	20.0	26.0	19	4	3	Single
100V N-Ch	HGB260N10SL	GB260N10SL	TO-263	100	40	2.4	26.0	30.0	17	3	2	Single
100V N-Ch	HGI200N10SL	GI200N10SL	IPAK	100	40	2.4	20.0	26.0	19	4	3	Single
100V N-Ch	HGD200N10SL	GD200N10SL	DPAK	100	40	2.4	20.0	26.0	19	4	3	Single
100V N-Ch	HGS220N10SL	GS220N10SL	SO-8	100	8	2.4	22.0	26.0	19	4	3	Single	Datasheet
